Description

The CAME GARD PX Automatic Barrier Kit (indexed under cabinet trade code 8K01RB-0800 or individual chassis code 803BB-0120) is an elite, high-speed vehicle access control system.

Engineered strictly for severe commercial use, major toll sectors, and massive multi-story parking structures, the GARD PX utilizes an advanced 36V DC Brushless Motor paired with an oil-bath mechanical reduction gearbox. This mechanical combination allows the system to achieve an outstanding tested benchmark rating of 5 to 10 Million MCBF (Mean Cycles Between Failures) while delivering continuous, non-stop operation.

Core Engineering Innovations

• 36V Digital Brushless Architecture: By completely eliminating mechanical carbon brushes, internal friction and heat generation are practically neutralized. The motor runs whisper-quiet, requires zero traditional brush maintenance, and delivers instant, precise torque adjustments across variable opening speeds.

• Rapid High-Speed Action: The brushless platform allows for highly aggressive acceleration profiling. The boom can actuate to a full 90° open position in a blistering 1.2 to 2.4 seconds, rapidly flushing high volumes of trailing traffic into car parks to prevent street-level gridlock.

• Anti-Shear Profile & Smart Electronics: The physical arm hinge assembly features an integrated safety protective cover to eliminate crush points during travel. Inside, the cutting-edge ZLB30 control board is positioned immediately under the upper crown for upright programming, utilizing a full-text multilingual graphic setup menu.

• Native Modbus Access Control: The ZLB30 board features an onboard RS485 interface supporting native MODBUS industrial communication protocols. It can interface cleanly with third-party automated ticketing columns, ANPR (Automatic Number Plate Recognition) cameras, or complex building management networks without requiring proprietary digital conversion bridges.

Technical Specifications

Feature	Specification
Cabinet Base Unit	GPX40MGS (Galvanized & Textured Charcoal Gray Painted Steel)
Mains Supply Input	100V AC to 240V AC (Switching Power Supply)
Motor Drive Platform	36V DC Brushless Engine
Max Net Clearance Passage	3.8 Meters (Accommodates up to a 4.0m physical arm)
Opening Speed (90°)	Adjustable from 1.2 to 2.4 seconds
Duty Cycle Profile	100% Continuous Service / Intensive Non-Stop Duty
Torque Output / Ingress	100 Nm / IP54
Safety Integration Layout	3 Configurable Safety Inputs (Supports 8k2 Resistive Safety Edges)

Standard Kit Box Contents (Deluxe Brushless Kit)

1. 1 x GPX40MGS GARD PX Cabinet: Features the 36V brushless motor, oil-bath reduction gears, and the advanced ZLB30 full-text display motherboard.

2. 1 x White Semi-Oval Aluminum Boom: 4.0m long, detailed with a integrated slot for safety edge profiles and light cords.

3. 1 x High-Visibility LED Signaling Package: Includes an integrated illuminated LED cabinet crown indicator and matching RG (Red/Green) dual-color safety LED light ropes to thread down the boom profile.

4. 1 x Internal Structural Reinforcement Bracket: Mandatory sleeve insert for spans exceeding 2.5 meters.

5. 1 x Calibrated Balancing Spring Assembly: Custom mechanical counterweight matching the 4m profile load.

6. 1 x G02807 Heavy Fixed Rest Post: Floor-anchor post to securely lock down and hold the boom tip when closed.

7. 1 x Pair of DIR10 Synchronized Photocells: Surface-mounted infrared anti-crush safety beams.

8. 1 x Bundle of 20 Reflective Warning Strips: High-visibility red vinyl adhesive indicators.
